Product Details:
Payment & Shipping Terms:
|
| Product Name: | Automatic Electronic Cigarette Liquid (Eye Drop，Essential Oil)) Filling, Plugging In And Capping Machine | Voltage: | 380V |
|---|---|---|---|
| Material Type: | Liquid | Category: | Filling Machine |
| Capacity: | Customize | ||
| High Light: | automatic liquid filling machine,beverage filling machine |
||
DX-DX8 Automatic Perfume Disinfectant Gel Water Spray Filling Production Line
Application
This production line is mainly used for fully automatic filling production for perfume, disinfectant, gel water, spray, etc.
Performance feature:
1. Workflow: bottle unscrambling --bottle washing (optional)--filling --adding sprayer --adding cap (optional) --capping -- labeling --ribbon printingcoding/ink jet printing (optional).
2. PLC control system, color touch screen display.
3. This machine has function of no bottle no filling (only peristaltic pump)/ no adding pump/ no adding outer cap (if has outer cap).
4. Stainless steel piston pump quantitative filling, pneumatic adding cap, liftingelevating screw capping. Has advantages of accurate filling measurement, smooth screw capping, and simple operation.
5. Cap positioning device, makes sure nozzlethe sprayerplastic pipe which too long or bendingcurved could go to bottleneck accurately.
6. Filling nozzles dive into bottles to fill and rise slowly to prevent foaming. Catch type flexible screw lid/head, adjustable tightness.
7. Main electrical elements adopts foreign well-known brands.
8. Machine shell is made ofby 304 stainless steel, machine is full compliance withmeets GMP requirements.
Technical parameter:
|
Model |
DX-DX8 |
|
Filling head number |
8 |
|
Adding pump head |
2 |
|
Capping head number |
2 |
|
Filling volume |
20-200ml (can be customized) |
|
Capacity
|
80-100 bottles/min
|
|
Filling accuracy |
≤ ±1% |
|
Pass rate |
≥ 98% |
|
Power supply
|
1 Ph. AC220V, 50/60Hz
|
|
Total power |
3.2 KW |
|
Net weight |
1000kg |
|
Overall dimension
|
L6000 × W1600 × H1550mm |
Machine Picture
Q&A
Q1: How to visit our Factory? (not a trade company)
A: Shanghai Airport→Pick you up
Q2: How does your factory do the quality control?
A: “QUALITY FIRST " We purchase qualified parts, test the machine every step when manufacturing. We have SGS certification and ISO certification.
Q3: How about the installation?
A: Option 1, our engineer install the machines for you, also train your staff until they can run the machine independently.
Option 2, you learn this in our factory.
Q4: Do you have after-sale service?
A: 1 Year Warranty and timeless maintenance service.
Q5: How about the payment term?
A: Payment term:1, T/T 30% , 70% before shipping.
